Weigh-Tronix P/N AWT27-500158
Overall Diameter : 4.500″
Classification : Axle
Overall Length : 20.30″
Hub # : 881
Inside Bearing Diameter : 3.542″
Outside Bearing Diameter : 2.625″
Mounting Hole : (1) 0.656″ Horizontal
Calibration : 2 1/4D
Cable Length : 21′
Termination : 5-Pin Military
Notes : same as 49090-0024 but longer seal area
$2,500.00
Quantity:
| Weight | 77 lbs |
|---|---|
| Dimensions | 24 × 12 × 12 in |
